Calculating Your VDP in Absence of An Instrument Approach Waypoint Data

Calculating Your VDP in Absence of An Instrument Approach Waypoint Data

In the world of aviation, Visual Descent Points (VDPs) play a significant role in ensuring a safe and smooth landing, particularly during non-precision approaches.

A recent incident highlighted the importance of VDPs, as a pilot's failure to brief a VDP may have contributed to a high altitude crossing of the threshold. If an approach has a VDP, the pilot should not descend below the Minimum Descent Altitude (MDA) prior to reaching the VDP.

The MDA for a non-precision approach is typically 500 feet Above Ground Level (AGL), and VDPs are denoted by a bold "V" on the approach chart. They are only published for straight-in instrument approaches to specific runways. However, VDPs might not be published due to obstructions or terrain.

When a VDP is not published, calculating it is essential for a safe visual descent. The standard method involves identifying the MDA and the runway threshold elevation, determining a safe and stable descent angle (usually around 3 degrees), calculating the vertical distance to lose from the MDA down to the runway threshold elevation, and using this to calculate the horizontal distance from the runway where you can start descending visually.

For example, if the MDA is 3440 ft and the runway elevation is 440 ft, the vertical distance is 3000 ft. For a 3° descent angle, the horizontal distance from the runway where you can start descending visually is approximately 9.6 nautical miles (NM) from the runway threshold.

It's important to note that VDPs provide a reference point to begin a visual descent below the MDA on non-precision approaches, helping achieve a stabilized descent path similar to a precision approach glidepath. If no VDP is published, the approach has not been assessed for obstacle clearance below MDA, so extra caution and obstacle awareness are required.

In practice, pilots often use published MDA and typical descent angles to calculate their own VDP distances for safe visual descent initiation. Advisory vertical descent angles (VDAs) published for some non-precision approaches can assist with this calculation but do not provide protected flight paths below MDA.

Boldmethod offers an Instrument Procedures course to help earn an instrument rating and master IFR flying, providing real-world flying tips and information. Subscribing to Boldmethod's email can keep you updated with the latest in aviation news and best practices.

Remember, while calculating a VDP can provide a useful guide, it is always crucial to maintain obstacle clearance and adhere to approach criteria. The resulting value is NOT DME, it is the VDP's distance from the runway threshold. Not every non-precision approach will have a VDP published, so it's essential to be prepared and calculated in such situations.

In conclusion, VDPs are a valuable tool in aviation, helping pilots navigate non-precision approaches safely and efficiently. By understanding their importance and knowing how to calculate them when necessary, pilots can ensure a smooth landing and a safe flight.

1. In the aviation industry, Visual Descent Points (VDPs) are crucial for a safe and smooth landing, particularly during non-precision approaches.
2. The Minimum Descent Altitude (MDA) for a non-precision approach is usually 500 feet Above Ground Level (AGL), and VDPs are shown as a bold "V" on the approach chart.
3. If a VDP is not published due to obstructions or terrain, it's essential to calculate it to ensure a safe visual descent.
4. When a VDP isn't published, pilots should use the MDA and typical descent angles to calculate their own VDP distances for safe visual descent initiation.
5. VDPs offer a reference point to begin a visual descent below the MDA, helping achieve a stabilized descent path similar to a precision approach glidepath.
6. If no VDP is published, extra caution and obstacle awareness are required because the approach hasn't been assessed for obstacle clearance below the MDA.
7. Boldmethod offers an Instrument Procedures course to help earn an instrument rating and master IFR flying, providing real-world flying tips and information.
8. While calculating a VDP can provide a useful guide, always maintain obstacle clearance and adhere to approach criteria, as the resulting value is NOT DME, it is the VDP's distance from the runway threshold.
