Essential Information on Controlled Airspace Class A

Essential Information on Controlled Airspace Class A

In the skies above, navigating radio failure in Class A airspace can be a challenging task for pilots. As of January 1st, 2020, the Federal Aviation Regulations (FAR) 91.225 mandates that aircraft operating in Class A airspace must be equipped with Automatic Dependent Surveillance-Broadcast (ADS-B) and Traffic Information Service-Broadcast (TIS-B) equipment. Here's what pilots need to know when faced with a radio failure in this controlled airspace.

When radio failure occurs under visual meteorological conditions (VMC) while operating in Class A airspace, the procedures are primarily governed by regulations addressing lost communications, with considerations for both Instrument Flight Rules (IFR) and Visual Flight Rules (VFR) circumstances.

Key procedures include squawking the appropriate transponder code, maintaining last assigned level or minimum safe altitude, climbing if receiving surveillance service, holding if instructed or necessary, and visual navigation.

Squawking the appropriate transponder code is crucial. In general, pilots should squawk 7600 to indicate lost communications. However, if a pilot decides not to continue under IFR (i.e., they become VFR and divert visually), they should squawk 7601 instead. This newer code signals to Air Traffic Control (ATC) that the pilot is in visual conditions and navigating by their own means outside the IFR system.

Maintaining last assigned level or minimum safe altitude is another essential procedure. After radio failure, pilots should maintain the last assigned altitude or a minimum safe altitude (if higher) for a period, typically around three minutes, then proceed according to previously acknowledged clearances or flight plan routing.

In the event that a pilot is under ATS surveillance and vectored, they should climb to the minimum safe altitude or last assigned level, maintain the last vector for two minutes, then continue as per the last clearance. If holding when loss occurs, the pilot should fly one more complete holding pattern and then proceed according to the latest acknowledged route clearance.

Visual navigation is particularly important since the conditions are visual and the aircraft is in Class A airspace—where IFR flight is normally mandatory. If the pilot loses communications but chooses to continue visually (which is unusual in Class A but hypothetically possible under specific conditions), the new squawk code 7601 helps ATC identify their situation and intention.

Emergency procedures may also be necessary. If required, pilots should use standard emergency communication attempts such as transmitting on guard frequency 121.5 MHz and/or trying backup radios. They should declare an emergency as needed and follow published lost communications procedures.

It's important to note that a "Flight Level" is an altitude at standard pressure. All aircraft flying above 18,000 feet Mean Sea Level (MSL) are required to set their altimeters to 29.92 inches. Class A airspace extends from 18,000 feet MSL to Flight Level 600 (FL600).

In case of a radio or transponder failure, pilots should follow the checklists for their airplane and try to problem-solve. ATC will usually assume you're experiencing an emergency if they lose both radio and transponder communication with you. Advanced aircraft have multiple backup sources for communication if radio problems are experienced, but older aircraft may have limited technology at their disposal.

Jets, turboprops, and some turbocharged and turbonormalized piston aircraft often fly in Class A airspace. Some operations where you'll commonly find deviations include high altitude skydiving and aerial survey work. Under FAR 91.135, deviations from the requirements of Class A can be issued by the ATC facility governing that section of airspace, but a written request at least 4 days before the proposed operation is required.

To operate in Class A airspace, maintaining two-way radio communications with ATC and using transponders with altitude reporting capabilities is necessary, as per FAR 91.215. ATC would rather aircraft divert safely under visual conditions, if possible, than remain in the IFR system without radios for hundreds of miles.

In high-risk security areas like Washington DC, it's possible that you might be intercepted by the military to confirm that you're having a legitimate emergency. If you encounter VFR conditions during a radio failure, you should continue the flight under VFR and land as soon as practical, regardless of being in Class A airspace or not.

If you begin to lose all electrical power in Class A airspace, in either visual or instrument conditions, you should declare an emergency and get to visual conditions as soon as possible. The worst case scenario is being stuck in instrument conditions with a dying electrical system. Aerobatics, ultralight vehicles, and parachute jumps are prohibited in Class A airspace without prior ATC permission.

These procedures ensure safe handling of radio failure events in controlled airspace, providing pilots with a guide to navigate these challenging situations effectively.

1. Navigating radio failure in Class A airspace can be a tough task for pilots, especially under Visual Flight Rules (VFR).
2. As of January 1st, 2020, the Federal Aviation Regulations (FAR) 91.225 mandates that aircraft operating in Class A airspace must be equipped with Automatic Dependent Surveillance-Broadcast (ADS-B) and Traffic Information Service-Broadcast (TIS-B) equipment.
3. Key procedures for pilots include squawking the appropriate transponder code, maintaining last assigned level or minimum safe altitude, climbing if receiving surveillance service, holding if instructed or necessary, and visual navigation.
4. Squawking the appropriate transponder code is crucial; pilots should use 7600 to indicate lost communications or 7601 if they become VFR and divert visually.
5. Maintaining last assigned level or minimum safe altitude is essential after radio failure; pilots should maintain this altitude for around three minutes.
6. If a pilot is under ATS surveillance and vectored, they should climb to the minimum safe altitude or last assigned level, maintain the last vector for two minutes, then continue as per the last clearance.
7. Visual navigation is important, especially in Class A airspace where IFR flight is normally mandatory, but the conditions are visual.
8. Emergency procedures may be necessary, including standard emergency communication attempts such as 121.5 MHz and backup radios.
9. A "Flight Level" is an altitude at standard pressure; Class A airspace extends from 18,000 feet MSL to Flight Level 600 (FL600).
10. If radio or transponder failure occurs, pilots should follow the checklists for their airplane and try to problem-solve, as ATC may assume an emergency.
11. Advanced aircraft have multiple backup sources for communication, but older aircraft may have limited technology.
12. Jets, turboprops, and some turbocharged and turbonormalized piston aircraft often fly in Class A airspace, with operations such as high altitude skydiving and aerial survey work having deviations.
13. To operate in Class A airspace, maintaining two-way radio communications with ATC and using transponders with altitude reporting capabilities is necessary.
14. If you encounter VFR conditions during a radio failure, you should continue the flight under VFR and land as soon as practical, regardless of being in Class A airspace or not.
15. In high-risk security areas like Washington DC, you might be intercepted by the military, and aerobatics, ultralight vehicles, and parachute jumps are prohibited in Class A airspace without prior ATC permission. These procedures help pilots safely navigate radio failure events in controlled airspace.
