Relax, strap in, and prepare yourself to become an aviator like a pro. In this guide, you'll learn the in's and out's of the E6B flight computer - the pilot's essential sidekick. Don't believe me? Ask any pilot around the globe, and they'll sing its praises.

Why you ask? Well, this indispensable gadget is much like a swiss army knife for flight calculations. It helps you chart your course, crunch numbers for time in transit, fuel usage, and vital wind shifts adjustments.

But wait, you might think, "In this day and age of smartphones and laptops, who needs an old school calculator?" Think again, my friend. The E6B is independent and doesn't need batteries or incessant software updates. You won't have to worry about it losing power or being faulty.

So, without further ado, let's dive into the world of the E6B.

The 411 on the E6B

First things first, what the heck is an E6B? Simply put, it's a pilot's manual flight computer - combined into one badass tool that acts as a slide rule, calculator, and graph plotter. And yes, it's still widely used today.

Why? Well, it gives immediate results, and that matters, especially when you're trying to pass the FAA exams. Mastering this tool will save you tons of time during exams by solving calculations in an instant.

In the real world, pilots use the E6B for a plethora of purposes. Take a cross-country flight, for instance. To plan it, you need to know:

• Time needed to fly between two points
• Your groundspeed (different from airspeed, thanks to ol' windy)
• Fuel consumption for the flight

The E6B can help you knock out all three.

But that's not all, it also assists in unit conversions, estimating wind correction angles, and figuring out density altitude. Oh, and there's even rulers and scales on the edges to help plot your route on sectional charts.

The E6B is divided into two halves:

• Circular slide rule side: Time, speed, fuel, air density calculations
• Wind side: Calculating wind correction angles and groundspeed

Now, let's take a closer look at both sides.

The Circular Slide Rule

The front side of the E6B houses the circular slide rule. Alright, it might look intimidating at first, but we can break it down into parts.

Middle and Outer Scales

Starting at the top, you'll see a large circular dial. The movable disk slots into it. The entire scale slides up and down the baseboard. The edge of the movable disk has another scale known as the middle scale. There's also a fixed dial with an outer scale on it.

The numbers on the scales aren't always meant to be read literally - they're context-dependent. So, 10 could be 100, 1000, or even 0.1 or 1. If you're confused about small numbers, like 3 or 7, just read 30 as 3 and 70 as 7 for those calculations.

The fixed dial also sports a prominently marked pointer, where the number 60 should be (although it's not always marked as such). It's used for rate-based calculations, such as fuel in gallons per hour or speed in miles per hour.

Inner Scale

Now, let's discuss the disk itself. The disk has another scale; this one is graduated in hours and minutes, also known as the inner scale. It's used for time calculations and is handy for ensuring you don't get lost in the continuous circular scale on the disk.

The Wind Side

The rear of the E6B is the wind side, which sports a rotating compass rose with a transparent plotting grid. There's a small hole in the middle called a grommet. This grommet serves as the origin of your plot.

The plotting grid allows you to mark wind speed and direction relative to your aircraft's course. Simply put, this side of the E6B functions as a reusable plotting graph.

Now that we've covered the basics, let's dive into how to use the E6B for time and speed calculations.

Time & Speed

Time en Route

Let's suppose we're flying a constant airspeed of 100 knots. How long would it take us to travel 40 nautical miles?

1. Align the rate pointer on the middle scale to 100 on the outer scale.
2. Find 40 on the outer scale.
3. Look at the number on the middle scale closest to 40 on the outer scale. In this case, it's 24. That means it would take 24 minutes to fly 40 miles at 100 knots.

Groundspeed Using Time and Distance

If you've flown 15 nautical miles in a straight line and it took you 10 minutes, what's your groundspeed?

1. Set 10 minutes on the middle scale opposite 15 on the outer scale.
2. Find the rate pointer. It points to 90 on the outer scale. That means our groundspeed was 90 knots.

Fuel Calculations

Calculating Range

If your groundspeed is 90 knots, how far can you fly if you have enough fuel for 4 hours?

1. Set the rate pointer at 90 on the outer scale.
2. Find 4:00 on the inner scale. That translates to 240 minutes since we can see it aligns with 24 on the middle scale. Look at the corresponding number on the outer scale. We can see that it aligns with one long mark after 35. That means 36.
3. Unfortunately, it seems our answer is higher than the flight distance you can usually cover in 4 hours, so let's read this as 360 nautical miles as an approximation.

Calculating Fuel Endurance

Let's suppose your aircraft requires 6 gallons of fuel per hour. You've got 22 gallons of fuel. How long can you fly?

1. Set the rate pointer to 60 on the outer scale (since we're not reading below 10, we read 60 as 6 here)
2. Find 22 on the outer scale. This number aligns with one mark after 3:30 on the inner scale. That means our fuel endurance is 3:40.

Calculating Fuel Consumption

Suppose you flew for 2 hours and 30 minutes, then refueled. Your fuel receipt shows it took 20 gallons to fill the tanks. What was your fuel consumption rate for the flight?

1. Find 2:30 on the inner scale.
2. Rotate the disk till this number aligns with 20 on the outer scale.
3. Now, you may be expecting an answer of 80 gallons per hour, but read my lips - life ain't fair sometimes. You should read 80 as 8 gallons per hour.

Density Altitude

Calculating Density Altitude

1. Find the pressure altitude. If you're in the aircraft, set the altimeter to 29.92 and read the altitude shown. If you don't have access to an altimeter, you can manually calculate the pressure altitude.
   1. Find out the current pressure reading from the ATIS or METAR.
   2. Subtract it from 29.92.
   3. Multiply it by 1000.
   4. If you end up with a negative number, subtract that reading from your current elevation. If the number is positive, add it to your elevation.
2. Find out the outside air temperature. Many aircraft have an outside air temperature gauge available.
3. Take a look at the pressure altitude window on the E6B's movable disk. Align the pressure altitude you calculated with the air temperature you've found.
4. The pointer above the window points to your density altitude.

Calculating True Airspeed

1. Follow steps 1-3 from the section above.
2. Find your Calibrated Airspeed on the movable disk's middle scale. For example, if it's 120, look for the number 12 on the scale.
3. Read the corresponding number on the outer scale. That's your true airspeed.

Calibrated airspeed and indicated airspeed are different beasts, but don't worry, you can use calibrated airspeed for an approximation in a pinch. Just remember the difference becomes significant above 200 knots, but most light aircraft don't usually reach those speeds.

Conclusion

There you have it – the E6B flight computer. If you want to top your game, check out our E6B Deep Dive at Pilot Institute to sharpen your skills even more! Ride the skies with confidence, and remember - a good pilot always has a trusty E6B by their side.
