Runway Turn Pad functionalities and purposes.
Hey there! Today, we're going to talk about the Turn Pads often found adjacent to some runways. The aviation world has quite a few intricate details, with runways, taxiways, aprons, and parking positions, all designed for safe and efficient flight operations. Let's delve into exactly what Turn Pads are and the significance they hold.
A Turn Pad is a designated area on a runway for aircraft to securely complete 180-degree turns.
Why do Airplanes Perform 180-Degree Turns on Runways?
In situations where there are no taxiways at the end of runways, specifically at airports with just one runway, landing aircraft might need to perform a 180-degree turn on the runway due to a lack of an exit taxiway. Similar circumstances exist for airplanes taking off. An aircraft wanting to align and take off from a runway without a taxiway will require taxiing backwards along the runway and then turning 180 degrees for the departure line-up position.
Additionally, in more exceptional instances, an airplane that abruptly aborts takeoff may need to turn 180 degrees on the runway at the end and vacate the runway or return to the takeoff position. To put it simply, Turn Pads ensure these turns are made without any mishaps.
It's worth noting that runway widths differ globally, with some being wider but some built narrower. Consequently, 180-degree turns on narrower runways are inherently sharper.
Turn Pads in ICAO Regulations
The International Civil Aviation Organization (ICAO) has evaluated Turn Pads as follows:
"Turn pads come in handy when an exit taxiway is absent at the runway end. A Turn Pad allows an airplane to turn back after landing and prior to take-off, and to ensure proper alignment on the runway." - ICAO DOC9981-2.4.1
"Airport operators should consider the possibility that certain airplanes might not be able to perform a 180-degree turn on narrower runways. Offering a suitable runway turn pad is advisable when no proper taxiway exists at the runway end." - ICAO DOC9981-2.2.7
Some Airports with Turn Pads
Let's take a gander at some airports around the world welcomed by turn Pads:
- Heathrow Airport, London, UK
- Kansai International Airport, Osaka, Japan
- Chicago O'Hare International Airport, Chicago, USA
- Cairo International Airport, Cairo, Egypt
- Los Angeles International Airport, Los Angeles, USA
These designated areas provide adequate space, clear markings, and tandem with runway safety areas to guarantee 180-degree turns on runways are carried out securely and smoothly. By combining an adequate physical space, clear markings, and integration with safety areas, turn pads safeguard airports across the globe by accommodating necessary 180-degree turns on runways, thereby minimizing risks of runway excursions or collisions with airport infrastructure.
Hope this breakdown of Turn Pads sheds light on why they're crucial for the safe execution of takeoffs and landings!
