Planning a cross-country flight requires careful preparation and organisation. Here's a guide on how to create a comprehensive flight plan template, complete with instructions and examples.

Template Structure

A well-structured flight plan template should include the following sections:

Flight Details: Date, aircraft information (type, tail number), pilot name, departure and destination airports.
Route and Waypoints: List ordered waypoints or navigational fixes with coordinates, distances between each leg, and estimated time en route.
Altitude and Airspace: Planned cruising altitude(s) and any notes on airspace classifications or restrictions.
Fuel Planning: Estimated fuel consumption per leg and total fuel required, including reserves.
Weather Briefing: Summary of weather conditions along the route and alternate airports.
Emergency Procedures: Contact information, radio frequencies, and contingency plans.
Notes and Remarks: Any special instructions or considerations.

Instructions for Use

Start by selecting the departure point and destination.
Identify mandatory or preferred waypoints (navigational aids, checkpoints).
Calculate distances and time required based on your aircraft’s groundspeed.
Determine the appropriate altitude according to flight rules and airspace.
Calculate fuel requirements considering all legs plus reserves.
Check weather forecasts and NOTAMs for all critical points.
Fill in all sections clearly in the template before departure.

Example

| Section | Example Details | |--------------------|---------------------------------------------| | Date | 2025-08-27 | | Aircraft | Cessna 172, N12345 | | Pilot | John Doe | | Departure | KJFK (John F. Kennedy Intl Airport) | | Destination | KBOS (Boston Logan Intl Airport) | | Route | KJFK → KISP → KDXR → KBOS | | Waypoints Distance | KJFK-KISP: 40 NM, KISP-KDXR: 50 NM, KDXR-KBOS: 20 NM | | Total Distance | 110 NM | | Cruising Altitude | 6,500 ft (VFR corridor) | | Estimated Time | 1 hr 20 mins | | Fuel Required | 10 gallons + 2 gallons reserve | | Weather | Clear skies, light winds | | Emergency Info | 121.5 MHz emergency frequency | | Remarks | Check NOTAM for KISP runway maintenance |

Tools for Digital Flight Planning

Apps like OzRunways can help create and customise flight plans by selecting waypoints from maps and adding them to your flight route, with options to set origins and modify plans efficiently.

For detailed regulatory and procedural information relevant to cross-country flight planning, refer to the FAA's Aeronautical Information Publication (AIP), which covers general rules, airspace, and navigational procedures.

Key Considerations

Check NOTAMs to ensure everything is up and running at your destination airport, as landing and finding out there is no avgas is a mistake to be made only once.
The heading to fly is the magnetic course, corrected for wind.
Write the point of departure and the next point in the same box for each leg. Ensure each waypoint's end corresponds to the first point in the next box as a gross error check.
Determine how long it will take to fly each leg based on the expected ground speed. Be aware of the wind direction to make adjustments if the fix doesn't appear on time.
To qualify as a 'cross-country' flight, the point of landing must be at least a straight-line distance of more than 50 nautical miles from the original point of departure and include a landing at a point other than the point of departure.
Measure the course from the start of each waypoint regarding true north (the straight grid lines on your chart).
Convert the true course to a magnetic one by knowing the variation in the area you are flying. Variation East means subtract the variation, and variation West means add the variation.
Draw a box next to each leg and write the course to steer, timing, and MSA in it. This makes it easier to see the information when airborne without flipping through the paper on your kneeboard.
Visual navigational fixes such as distinctive bends in roads or rivers, intersections, unusual shaped lakes, large landmarks, headlands, airfields can be used for navigation.
Work out timings by determining how long you'll need to fly on each leg, and draw a big wind arrow on your chart as a gross error check.
Be selective in your cruising altitude, choosing odd altitudes for headings 0-179 degrees and even altitudes for headings 180-359 degrees, to reduce the chances of meeting someone mid-air.
Using the "one in sixty" rule, draw lines on either side of the track from each fix that are 5 degrees different from the track. This helps in identifying deviations from the intended track and making heading corrections.
The minimum safe altitude (MSA) should be written down on the flight plan for each leg, calculated by adding 500 feet to the map's high points and offering 5 nautical miles of clearance on either side.
Calculate fuel burn by knowing how long you are flying, as the best pilots always keep an eye on their fuel to have a good idea of their endurance and to identify leaks early.
Ideally, fly according to the semi-circular rule, which is described in the FAA Website.

By following this guide, you'll create a comprehensive cross-country flight plan that serves as your 'to-do list' and route checker, ensuring a smooth and safe journey.
